7-Axis Cobot has various functions such as rapid deployment, traction teaching and collision detection. lt is particularly suitable for flexible production lines with compact layout and high precision to conduct precision assembly, product packaging, polishing, testing, machine loading and unloading and other industrial operations. 7-Axis Cobot, with its high flexibility, precision, and safety, will open up a brand new way of industrial production and lead the new era of human-machine collaboration.
1. More Flexible
● With 7 degrees of freedom, the robot can work well in compact space.
2. Easter-to-use
● With Traction Teach
● Programming, Less limitation to robot user.
3. Safety
● Collision detection function enables human robot collaboration.
4. More Accurate
● Repeatability up to ±0.02mm.
5. Economic Efficient
● Power consumption 250W
| X5-800 7A | ||
| Max Payload | 5kg（5.5kg*1） | |
| Degress of Freedom | 7 | |
| Max TCP Speed | 2.0m/s | |
| Max Straight-line Speed | 1.0m/s | |
| Reach | 800mm | |
| Repeatability | ±0.02mm | |
| Joint | Range | Max Speed |
| J7 | ±180° | 180°/s |
| J6 | ±110° | 180°/s |
| J5 | ±180° | 180°/s |
| J4 | ±115° | 180°/s |
| J3 | ±180° | 180°/s |
| J2 | ±105° | 180°/s |
| J1 | ±180° | 180°/s |
| Tool Interface | GB/T 14468.1-50-4-M6(eqv ISO 9409-1) | |
| I/O Control Box I/O | 14 Dig I/O, 24V, 0.5A | |
| End Joint I/O | 2 Dig I/O, 24V, 1A | |
| Power Supply | 230VAC (-15%~+10%), 50-60Hz | |
| Power Consumption | Typical Power Consumption 400W | |
| Robot Dimesions | 1285x220x240mm | |
| Control Box Size | 530x480x180mm | |
| Installation | Installed in any Direction | |
| AmbientTemperature Range | -10℃-45℃ | |
| StorageTemperature Range | -40℃-55℃ | |
| IP Class | IP54 | |
| Robot Package Size | 735x635x350mm | |
| ControlSystem PackageSize | 698x588x450mm | |
| Net/Gross Weight | 24kg/33kg | |
